Couplers, Crossguide
Microtech's Couplers, Crossguide are engineered, designed, and manufactured "in house".
Typical Electrical Specifications
| Size | Frequency | VSWR Primary Arm | Coupling Variation + or - (dB) |
|---|---|---|---|
| WR 22 | 33.00-50.00 GHz | 1.10 | 3.0 |
| WR 28 | 26.50-40.00 GHz | 1.10 | 2.0 |
| WR 34 | 22.00-33.00 GHz | 1.10 | 2.0 |
| WR 42 | 18.00-26.50 GHz | 1.10 | 2.0 |
| WR 51 | 15.00-22.00 GHz | 1.10 | 1.5 |
| WR 62 | 12.40-18.00 GHz | 1.10 | 1.5 |
| WR 75 | 10.00-15.00 GHz | 1.10 | 1.5 |
| WR 90 | 8.20-12.40 GHz | 1.10 | 1.5 |
| WR 102 | 7.00-11.00 GHz | 1.10 | 1.5 |
| WR 112 | 7.05-10.00 GHz | 1.10 | 1.2 |
| WR 137 | 5.85-8.20 GHz | 1.10 | 1.0 |
| WR 159 | 4.90-7.05 GHz | 1.10 | 1.0 |
| WR 187 | 3.95-5.85 GHz | 1.10 | 1.0 |
| WR 229 | 3.30-4.90 GHz | 1.10 | 1.0 |
| WR 284 | 2.60-3.95 GHz | 1.10 | 1.0 |
| WR 340 | 2.20-3.30 GHz | 1.10 | 1.0 |
Typical Mechanical Specifications
| Size | Frequency | Flange Equiv. | "A" Dimension (Max inches) | "B" Dimension (Max inches) | "C" Dimension Jack |
|---|---|---|---|---|---|
| WR 22 | 33.00-50.00 GHz | Cover | 2.25 | 3.38 | 2.9 |
| WR 28 | 26.50-40.00 GHz | Cover | 2.25 | 3.38 | 2.9 |
| WR 34 | 22.00-33.00 GHz | Cover | 2.25 | 3.38 | - |
| WR 42 | 18.00-26.50 GHz | Cover | 2.25 | 3.38 | SMA |
| WR 51 | 15.00-22.00 GHz | Cover | 2.5 | 3.50 | SMA |
| WR 62 | 12.40-18.00 GHz | Cover | 2.50 | 3.50 | SMA |
| WR 75 | 10.00-15.00 GHz | Cover | 3.00 | 4.50 | SMA |
| WR 90 | 8.20-12.40 GHz | Cover | 3.00 | 4.50 | SMA |
| WR 102 | 7.00-11.00 GHz | Cover | 3.00 | 2.25 | SMA |
| WR 112 | 7.05-10.00 GHz | Cover | 4.00 | 6.00 | SMA |
| WR 137 | 5.85-8.20 GHz | Cover | 5.00 | 7.50 | N |
| WR 159 | 4.90-7.05 GHz | CPRF | 5.00 | 7.50 | N |
| WR 187 | 3.95-5.85 GHz | CPRF | 5.00 | 7.50 | N |
| WR 229 | 3.30-4.90 GHz | CPRF | 6.00 | 9.00 | N |
| WR 284 | 2.60-3.95 GHz | CPRF | 8.00 | 12.00 | N |
| WR 340 | 2.20-3.30 GHz | CPRF | 10.00 | 15.00 | N |
ORDERING INFORMATION |
 |
 |
 |
|
|
|||
| STYLE "T" | STYLE "X" | STYLE "C" |
Notes
1. Standard couplings available are 20, 30, 40, 50, and 60. Others values available on special order. Specify by adding
coupling and style desired as a suffix to the part number. Example: 233317X-20.
2. Coaxial secondary outputs are also available. Contact the factory or our local Manufacturer's Representative for
details.
3. Nominal directivity is 20 dB.
4. Couplers that conform to MIL-C-15370 are also available.
